Air hose Retractor
TYPE 7221 / 7222
Load range: 2.0 - 14.0 kg | Cable travel: 3000 m
- Cable travel: A longer cable is available upon request
- Spiral hoses available in 9 x 13 and 11 x 16 variants
- Max. operating pressure 10 bar
- Safe suspension with freely rotating and swivelling screw-type spring hook
- Housing of very impact-resistant and abrasion-resistant plastic
- Cable drum of abrasion-resistant plastic
- High-strength special suspension spring
- High-strength steel cable
- Infinitely adjustable cable stop buffer
- Cable wedge allows infinite adjustment of cable length
- Screw-type spring hook for load suspension
- Infinitely variable load setting
- Available without (Type 7221) or with (Type 7222) ratchet lock
- Closed unit
- Rigid, impact-resistant design
- Electrically insulated suspension via screw-type spring hook (freely rotating and swivelling design)
- Includes safety chain as fall protection
- Mechanism for locking the cable drum
- High-strength special suspension spring
- Spring fracture safeguard is standard
- Includes ferrule for securing the cable end
- Screw-type spring hook for load suspension
- GS-certified
Hose edition 9 x 13 mm
| Itemw/o Ratchet lock |
GTINw/o Ratchet lock |
Itemwith Ratchet lock |
GTINwith Ratchet lock |
Load rangein kg |
Cable travelin mm |
Own weightw/o Ratchet lock in kg |
Own weightwith Ratchet lock in kg |
InquiryPrice/Details |
| 7221 0801 01 |
4262403191228 |
7222 0801 01 |
4262403191624 |
2.0 - 5.0 |
3000 |
3.9 |
4.0 |
|
| 7221 0801 02 |
4262403191235 |
7222 0801 02 |
4262403191631 |
4.0 - 8.0 |
3000 |
4.2 |
4.4 |
|
| 7221 0801 03 |
4262403191242 |
7222 0801 03 |
4262403191648 |
7.0 - 10.0 |
3000 |
4.2 |
4.4 |
|
| 7221 0801 04 |
4262403191259 |
7222 0801 04 |
4262403191655 |
10.0 - 14.0 |
3000 |
4.4 |
4.5 |
|
Hose edition 11 x 16 mm
| Itemw/o Ratchet lock |
GTINw/o Ratchet lock |
Itemwith Ratchet lock |
GTINwith Ratchet lock |
Load rangein kg |
Cable travelin mm |
Own weightw/o Ratchet lock in kg |
Own weightwith Ratchet lock in kg |
InquiryPrice/Details |
| 7221 0801 11 |
4262403191266 |
7222 0801 11 |
4262403191662 |
2.0 - 5.0 |
3000 |
4.2 |
4.3 |
|
| 7221 0801 12 |
4262403191273 |
7222 0801 12 |
4262403191679 |
4.0 - 8.0 |
3000 |
4.6 |
4.7 |
|
| 7221 0801 13 |
4262403191280 |
7222 0801 13 |
4262403191686 |
7.0 - 10.0 |
3000 |
4.6 |
4.7 |
|
| 7221 0801 14 |
4262403191297 |
7222 0801 14 |
4262403191693 |
10.0 - 14.0 |
3000 |
4.8 |
4.9 |
|
